Regenerative high-power programmable DC load

SKU : FTR9000

FTR9000 series is a regenerative programmable DC electronic load.

แบรนด์ :Faith

Product description

Single unit: voltage: 0 ～ 2250V Current: 0 ～ 4500A Power: 0 ～ 180kW;
The extended power of master slave parallel operation can reach 1.8MW;
Voltage precision: 0.05%+0.05% F.S; Current accuracy: 0.1%+0.1% F.S;
The power factor is 0.99, and the overall efficiency is higher than 93%;
Automatic compensation for wire loss;
It has the functions of constant voltage, constant current, constant power and constant resistance;
Voltage and current slew rate can be set;
With battery discharge test function;
It has sequence and waveform functions, and can realize complex voltage and current waveforms, such as automobile electronic test voltage waveform and user-defined waveform;
Over voltage, over current, over power, over temperature, low voltage, power down, island protection and other comprehensive protection functions;
High voltage isolation digital, analog, monitoring and control interfaces;
The communication interface is equipped with LAN, USB as standard, RS485, CAN or GPIB as options;
The communication protocol supports SCPI, MODBUS, CAN-OPEN (optional) protocols, and provides the upper computer and SDK development package for secondary development;
TFT color LCD screen, Chinese, English and traditional Chinese menu interface
Intelligent fan control;
Standard 19 inch rack design, pulley design can be selected for more than 16U.
